About Gaudi Circular
Two-point fixing for besa box or surface mounting. Wire suspension 2.0 m with ceiling cup and integrated friction lock for height adjustment. Recessed ceiling cup available as accessory. Mounting plate should be used for recessed installation.
LED luminaire equipped with three 2.0 m wires, of which two feed the luminaire. Ceiling cup with snap-in terminal block 5x2.5 mm². Driver included in ceiling cup. Surface mounted mains cable possible.
Body of spun aluminium, opal acrylic cover, metal ceiling cup. White (RAL 9016) structured or black (RAL 9005) structured finish.
DALI/Pahse-pulse control as standard.
4000 K: Ra (CRI) min. 80, L70 50 000 h, MacAdam 3 SDCM.
Driver life time: up to 100.000 h/10 % (max failure).
Downloads Gaudi Circular
Marking of product sheet
Functions Gaudi Circular
|W||Weight, kg||Diameter, mm||Colour||CCT (K)||lm||lm/W||Art.No.|
Accessories Gaudi Circular
Light distribution Gaudi Circular
