Combilume Direct/Indirect

Installation
Wire suspended via friction locks secured to the luminaire. Wire suspension ordered separately, see Accessories.

Connection
Connection is made at the end of the luminaire, see the dimensional drawing. 5-way snap-in terminal block at one end of the luminaire, 1-phase through-wiring possible.

Design
Luminaire body of extruded aluminium in white (RAL 9016) or alu-grey (RAL 9006) textured enamel.

Louvre
Delta – microprism louvre in acrylic (PMMA) with good optical characteristics.

LED-information
4000 K: Ra (CRI) min. 80, MacAdam 3 SDCM.
2700-6500 K: Ra (CRI) min. 80, MacAdam 3 SDCM.
Driver life-time: up to 50.000 h/10 % (max failure).

Miscellaneous
Combilume uses side emitting LED technology for a glare-free light.

Luminaires with Tunable White (2700-6500 K) are equipped with DALI device Type 8 driver and are listed as 4000 K in the table – the range is shown in the brackets.

Environment images


Details


Despite it’ compact dimensions, the technical solution is contained within the frame.

Despite it’ compact dimensions, the technical solution is contained within the frame.

Combilume direct/indirect achieves the required for  3000 cd/m² as per the EN 12464-1 standard.

Combilume direct/indirect achieves the required for 3000 cd/m² as per the EN 12464-1 standard.

Marking of product sheet

Document added to your cart

Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097
51 300x1200 7.0 White 3000 5600 110 L80B50 75.000 h 12101
51 300x1200 7.0 Alu grey 3000 5600 110 L80B50 75.000 h 12102
51 300x1200 7.0 White 4000 5700 112 L80B50 75.000 h 12103
51 300x1200 7.0 Alu grey 4000 5700 112 L80B50 75.000 h 12104
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055-402
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068-402
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096-402
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097-402
51 300x1200 7.0 White 3000 5600 110 L80B50 75.000 h 12101-402
51 300x1200 7.0 Alu grey 3000 5600 110 L80B50 75.000 h 12102-402
51 300x1200 7.0 White 4000 5700 112 L80B50 75.000 h 12103-402
51 300x1200 7.0 Alu grey 4000 5700 112 L80B50 75.000 h 12104-402
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (Tunable White). Luminaire is listed in 4000 K, range in brackets.
63 300x800 4.0 White 4000 (2700–6500) 4975 (4449–5217) 79 (71–83) L70B50 55.000 h 12085
63 300x800 4.0 Alu grey 4000 (2700–6500) 4975 (4449–5217) 79 (71–83) L70B50 55.000 h 12086
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055-459
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068-459
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096-459
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097-459
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055-448
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068-448
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096-448
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097-448
51 300x1200 7.0 White 3000 5600 110 L80B50 75.000 h 12101-448
51 300x1200 7.0 Alu grey 3000 5600 110 L80B50 75.000 h 12102-448
51 300x1200 7.0 White 4000 5700 112 L80B50 75.000 h 12103-448
51 300x1200 7.0 Alu grey 4000 5700 112 L80B50 75.000 h 12104-448
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055-458
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068-458
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096-458
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097-458
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055-457
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068-457
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096-457
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097-457
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (Tunable White). Luminaire is listed in 4000 K, range in brackets.
63 300x800 4.0 White 4000 (2700–6500) 4975 (4449–5217) 79 (71–83) L70B50 55.000 h 12085-477
63 300x800 4.0 Alu grey 4000 (2700–6500) 4975 (4449–5217) 79 (71–83) L70B50 55.000 h 12086-477
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (Tunable White). Luminaire is listed in 4000 K, range in brackets.
63 300x800 4.0 White 4000 (2700–6500) 4975 (4449–5217) 79 (71–83) L70B50 55.000 h 12085-478
63 300x800 4.0 Alu grey 4000 (2700–6500) 4975 (4449–5217) 79 (71–83) L70B50 55.000 h 12086-478
Text som beskriver tabellen
W Module Weight, kg Colour CCT (K) lm lm/W Useful life Art.No.
LED (system)
50 300x800 4.0 White 4000 4700 94 L80B50 75.000 h 12055-449
50 300x800 4.0 Alu grey 4000 4700 94 L80B50 75.000 h 12068-449
50 300x800 4.0 White 3000 4700 94 L80B50 75.000 h 12096-449
50 300x800 4.0 Alu grey 3000 4700 94 L80B50 75.000 h 12097-449
51 300x1200 7.0 White 3000 5600 110 L80B50 75.000 h 12101-449
51 300x1200 7.0 Alu grey 3000 5600 110 L80B50 75.000 h 12102-449
51 300x1200 7.0 White 4000 5700 112 L80B50 75.000 h 12103-449
51 300x1200 7.0 Alu grey 4000 5700 112 L80B50 75.000 h 12104-449

Complete wire suspension for T-bars 25 mm

Complete wire suspension for T-bars. White ceiling cup. L=1.0 m. Incl. mains cable 3x1.0 mm²

Art.No.
Large ceiling cups for T-bars 25 mm (94881+94589) 94445

Connection cable between control unit and controller to e-Sense Connect

Art.No.
Connection cable between control unit and controller to e-Sense Connect 86303

Control unit to e-Sense Connect

The control unit is the link between the luminaires and their control functions. Communication takes place over 2.4 GHz. The communication technology called cognitive radio multiplexer, and which means that the communication is always secured in the best possible way. If other devices, e.g. WLAN networks, communicate on the same bandwidth then the signal moves to a less popular space/frequency.

The control unit is permanently connected to a controller adapted to user requirements.

Art.No.
Control unit to e-Sense Connect 86300

DALI Switch Cross

Control panel for controlling the intensity and color temperature (stepless) of DT8 compliant Tunable White luminaires. For mounting on an appliance box. Requires no programming. Separate DALI PSU is required.

Art.No.
DALI Switch Cross 86354

DALI XC

DALI XC
4-channel control module for momentary push button mounted in appliance box . Used together with DT8 compliant Tunable White luminaires to regulate the intensity(dimming) and control the color temperature steplessly. Only wiring required, no programming. Separate DALI PSU is required .

Art.No.
DALI XC 86132

Remote control (for grouping) to e-Sense Connect

Communication in the system takes place between the luminaires’ RF units and the control unit. The remote control is only used for programming. The remote control uses RF signals rather than IR signals, which means that you only need to direct it towards luminaires when programming them.

Art.No.
Remote control (for grouping) to e-Sense Connect 86301

Wire suspension for single installation

Complete wire suspension. Grey ceiling cup. L=1.0 m. Incl. mains cable 5x1.0 mm².

Art.No.
Small + large ceiling cup, white/pair (94327+91701) 91691

Wire suspension for single installation

Complete wire suspension. Grey ceiling cup. L=1.0 m. Incl. mains cable 5x1.0 mm².

Art.No.
Small + large ceiling cup, white/pair (94327+91701) 91691

Wire suspension for single installation

Complete wire suspension. Grey ceiling cup. L=1.0 m. Incl. mains cable 5x1.0 mm².

Art.No.
Small + large ceiling cup, white/pair (94327+91701) 91691
Large ceiling cups for T-bars 25 mm, white/pair (94881+91703) 91694

Wire suspension kit

Complete wire suspension, ceiling cup and mains cable 3x1.0 mm². L=1.0 m.

Art.No.
Small + large ceiling cup, white/pair (94327+94588) 94301
Large ceiling cups, white/pair (94296+94588) 94444
Dimensions picture
Light distribution
Delta 300x800

Delta 300x800
